Pika IR (900-1700nm)
900 - 1700 nm
High-Speed Infrared

The Pika IR (formerly Pika NIR-320) is a high-speed, cost-effective hyperspectral camera that covers the Near-Infrared (NIR) spectral range. It is our most popular imager for machine vision applications.

The Pika IR can be used in our airborne, laboratory, and outdoor hyperspectral systems, as well as standalone or integrated into your system with our programming guidance document.

A plot of SNR vs. wavelength for the Pika IR is available in here.

Please contact us for product and pricing information.

Photos of Pika IR (900-1700nm)

900 - 1700 nm
High-Speed Infrared

Pika IR Hyperspectral Imaging Camera: Top

Pika IR Hyperspectral Imaging Camera: Bottom

Pika IR Hyperspectral Imaging Camera: Side

Hyperspectral data of oranges from a Pika IR hyperspectral camera.

Specifications

Spectral Range (nm)900 - 1700

Spectral Channels168

Spectral Resolution - FWHM (nm)8.8

Spatial Pixels320

Max Frame Rate (fps)

508

f/#1.8

InterfaceGigE

Weight, w/o lens (kg)2.95

Dimensions (mm)264 x 115 x 88

CertificationsCE, RoHS 3

Hyperspectral Terminology

Terminology Definitions LINK

Objective Lenses for Pika IR

Focal Length (mm)FOV (deg)IFOV (mrad)

1005.50.30

757.30.40

5011.00.60

2521.71.20

1633.41.90

861.93.75

677.35.00

View All Objective LensesView all lenses
