Benchtop System - Reflectance of Large Samples
Benchtop System - Reflectance of Large Samples
The Benchtop System - Reflectance of Large Samples Configuration is used to acquire reflectance data of larger objects that are difficult to move, such as trees, art, animals, and acquariums. The hyperspectral camera and lights are mounted directly to a long translation stage, which can be mounted horizontally or vertically. During data acquisition the stage moves, translating the imager and lights across the stationary subject. The imager and stage are controlled using Spectronon software.
A high-intensity halogen lighting assembly provides stabilized broad-band illumination across the entire measured spectra.
Resonon's systems contain all hardware and software necessary to acquire and analyze hyperspectral data.
Benchtop systems can be fitted with any of Resonon's hyperspectral imaging cameras covering the 350 - 1700 nm spectral range.
System components:
- Hyperspectral imaging camera
- Objective lens
- Linear translation stage
- Mounting tower
- Lighting assembly with stabilized power supply
- Spectronon software pre-loaded onto a laptop computer
- Calibration tile

Photos of Benchtop System - Reflectance of Large Samples



Specifications
Power requirementsCompatible with 110V / 220V outlets.
Stage Length (cm/in)89 / 35
Tower Height (cm/in)81 / 32, Custom lengths possible.
