Pika IR-L+ (925-1700nm)
925 - 1700 nm
Lightweight, High-Precision Infrared

The Pika IR-L+ imager is a high spatial and spectral resolution Near-Infrared (925-1,700 nm) imager in a lightweight, compact format. It is well suited for airborne applications, yet compatible with all imaging platforms (airborne, benchtop, outdoor, or machine vision).

A plot of SNR vs. wavelength for the Pika IR-L+ is available in here.

Please contact us for product and pricing information.

For a compact, lightweight Visible light spectral range option, please see the Pika L.

For higher imaging speeds, please see the Pika IR-L.

Photos of Pika IR-L+ (925-1700nm)

925 - 1700 nm
Lightweight, High-Precision Infrared

Pika IR-L+ Hyperspectral Imaging Camera: Front

Pika IR-L+ Hyperspectral Imaging Camera: Back

Hyperspectral data of forest from a Pika IR-L+ airborne hyperspectral imaging system

Specifications

Spectral Range (nm)925 - 1700

Spectral Channels470

Spectral Resolution - FWHM (nm)3.8

Spatial Pixels

640

Max Frame Rate (fps)176

f/#1.8

InterfaceGigE

Dimensions (mm)210 x 68 x 63

Weight, w/o lens (kg)

1.01

CertificationsCE, RoHS 3

Hyperspectral Terminology

Terminology Definitions LINK

Objective Lenses for Pika IR-L+

Focal Length (mm)FOV (deg)IFOV (mrad)

1005.50.15

757.30.20

5011.00.30

2521.70.60

1633.40.90

861.91.90

677.32.50

View All Objective LensesView all lenses
