Pika L-F (420-980nm)
420 - 980 nm
Fast VNIR

The Pika L-F is a fast (up to 585 frames per second) hyperspectral camera that covers the Visible + Near-Infrared (VNIR) spectral range. It is designed for machine vision applications where speed is critical.

The Pika L-F is ideally suited for machine vision systems, but can also be used in our laboratory and outdoor hyperspectral systems, as well as standalone or integrated into your system with our programming guidance document.

A plot of SNR vs. wavelength for the Pika L-F is available in here.

Please contact us for product and pricing information.

Photos of Pika L-F (420-980nm)

420 - 980 nm
Fast VNIR

Videos for Pika L-F (420-980nm)

Pika L-F high-speed sorting of lentils

Specifications

Spectral Range (nm)420 - 980

Spectral Channels224

Spectral Resolution - FWHM (nm)3.1

Spatial Pixels720

Max Frame Rate (fps)

585

f/#2.8

InterfaceUSB 3.0

Dimensions (mm)115 x 104 x 66

Weight, w/o lens (kg)0.64

CertificationsCE, RoHS 3

Hyperspectral Terminology

Terminology Definitions

Objective Lenses for Pika L-F

Focal Length (mm)FOV (deg)IFOV (mrad)

704.00.22

505.70.30

2511.30.60

2312.30.66

1716.60.88

1617.40.94

1223.41.30

834.41.90

644.92.50

View All Objective LensesView all lenses
