SpectralSight™
Automated Hyperspectral System with RVS Software

The SpectralSight™ System is used to rapidly acquire and analyze hyperspectral data in both laboratory and industrial settings.

Resonon's Real-time Vision System (RVS) software automatically detects objects on the conveyor belt and creates a datacube for each object. Machine learning algorithms in RVS can be used to classify objects on the belt or quantify a variable via regression, enabling optical sorting.

Datacubes collected with RVS can be analyzed in our Spectronon™ software.

The SpectralSight™ system can be fitted with Resonon's Pika L, Pika L-F, Pika IR, Pika IR+, Pika IR-L, and Pika IR-L+ cameras, covering the 400 – 1700 nm spectral range.

Standard System Components:

Hyperspectral camera and Objective lens
Conveyor belt system (gray or food-processing blue belt options)
Mounting tower and calibration tile
6-fixture halogen flood light with stabilized power supply
High-performance desktop computer with RVS software preloaded

Options:

A SpectralSight™ Conversion Kit is available to turn an existing Resonon Benchtop System into a SpectralSight™ System.
A halogen line light or a hyperspectral LED light (VNIR and IR option) can be purchased instead of the 6-fixture halogen light. For guidance on which to choose for your specific application, please see this comparison.

Resonon's hyperspectral imaging systems are rugged and built to last, and we guarantee their performance. All products include a two-year warranty. For details, please see our Warranty and Repairs page.

We offer Virtual and In-Person training to help you begin taking and analyzing data quickly.

Photos of SpectralSight™

Automated Hyperspectral System with RVS Software

SpectralSight™ with RVS classifying lentils at over 500 frames / second.

SpectralSight™ with RVS classifying almonds, almonds shells, and chipped almonds.

Comparison table of different RVS software packages

Videos for SpectralSight™

SpectralSight™ with RVS Software Intro

RVS Software Classification Demo

Specifications

Power requirements120 or 240 VAC

Tower Height (mm/in)890 / 35

Conveyor Belt Width (mm/in)203/8

Conveyor Belt Length (mm/in)559/22

CertificationsCE, RoHS 3
