Pika XC2

400 - 1000 nm

Pika XC2

400 - 1000 nm

Photos of Pika XC2

400 - 1000 nm

Specifications

Spectral Range (nm)400 - 1000
Spectral Resolution (nm)1.3
Spectral Channels447
Spatial Channels1600
Max Frame Rate (fps)165
Bit Depth12
Connection OptionsUSB 3.0
Size (cm/in)10.1 x 27.5 x 7.4 / 4.0 x 10.8 x 2.9
Weight (kg/lb)2.2 / 4.9
Power requirements3.4 W
Operating Temperature Range (C/F)5 - 40 / 41 - 104
f/#2.4
Signal-to-Noise Ratio (Peak)366 (2x bin), 518 (4x bin)
Average RMS Spot Radius (µm)6
Smile, Peak-to-Peak (µm)2
Keystone, Peak-to-Peak (µm)5
Spectral Pixels894
Dispersion per Pixel = Spectral Sampling (nm)0.67
Pixel Size (µm)5.86
Hyperspectral Terminology GlossaryClick here

Objective Lenses for Pika XC2

Focal Length (mm)FOV (rad)IFOV (mrad)
707.70.17
5010.70.24
2323.10.52
1730.80.71
1242.71.00
860.81.5
6762.00
View All Objective LensesView all lenses
